Configuring Frame Relay Ports

Configuring Frame Relay
Once the necessary Node, Line Processor, and protocol parameters have been con-
figured, press at the Port Configuration Menu (or
[A]
When prompted, enter:
LP number of the RLP containing the port:
FRX4000 or FRM. (The default is
Port number (see port locations in Chapter 5):
The display for an existing port will show the configured parameter values, while the
display for a new port will show default database values. (See Table 6-2 on page 6-14
and Table 6-3 on page 6-15.) The following figure is an example of an existing port.
Frame Relay Port Parameters (screen 1 of 2)
* R LP: 0 Port: 5
* I /O: V.35
A Port Typ e
B Phys ical Port In terface
C Blocked Port Flag
D Line Speed
E Maximum Bytes per Frame
F Logical DC E
G Generate Clock
H R cv Clock (TT) from DTE
I Link Management
J N 1 Polling Coun t
K N 2 Error Thres hold
L N 3 Monitored Events Cou nt
M T1 Link Integrity Timer
N T2 Polling V erification Timer
O A dditional Parameters
P On-Line System Memory Ch anges
Option:
Figure 6-3 Frame Relay Port Screen 1
The above is an example of an existing frame relay port. On an FRX4000
with
Physical Port Interface
different.
Pressing will display a screen similar to the following.
[O]
[A], [C], [A]
0–7 for FRX6000,
.) (LP numbers are described in Chapter 4.)
0
. (The default is
0–7
Nod e Name=nod e_xyz
Link State: Lin kup
Datab ase System Memory
Frame R elay Frame R elay
V.35 V.35
N N
64K bp s 64K bp s
1600 1600
N N
N N
N N
2,A nnex D 2,A nnex D
6 6
3 3
4 4
10 10
15 15
Y
[A],[C],[A] from Main Menu
(item B) configured as
from the Main Menu.
0 only for
.)
0
, items G and H will be
DSU
6-9
