Configuring Node Defaults

3-4
Node Defaults are a set of parameters that identify an FRX/FRM for purposes of
remote control, file transfers, and/or alarm reporting to or from other FRXs or FRMs,
and define connections between the FRX/FRM and a NetView manager device.
Press at the Node Configuration Menu to display a screen similar to Figure 3-1.
[C]
This is the first of three Node Defaults screens—pressing
the display among the three screens.
The first two screens contain parameters that apply to all users. The third screen con-
tains parameters used in sessions between a NetView host and the NetView service
point function in the FRX/FRM. If the NetView function will not be used, the third
screen does not have to be configured.
N ode Defaults Con figu ration (Screen 1 of 3)
A Node N ame
B Remote Control I D
C Remote Control Pwd
D File Tran sfer ID
E File Tran sfer Pwd
F Collectin g FRX/FRM I D
G Collectin g FRX/FRM Pwd
H Primary Alarm Outpu t ID
I Primary Alarm Outpu t Pwd
J Secon dary Alarm Outp ut I D
K Secon dary Alarm Outp ut Pwd
L On -Lin e Temp orary Chan ges
Option:
Figure 3-1 Node Defaults Configuration Screen 1
If there is a error in the configuration for alarm reporting, a message will
be displayed at the top or bottom of the screen. The possible messages are
described on page 3-12.
Primary Output ID
FRM only) serial/parallel ports. If a serial port is specified, no associated
password (
Pwd
ating parameters (listed in Table 3-2) for the port will be displayed.
Although the entries for the various passwords appear blank,
default values exist; if you change one, be sure you do not
duplicate an existing password.
Datab ase Sys tem Memory
nod e_xyz nod e_xyz
N
[A],[A],[C]
and
Secondary Output ID
) entry will be displayed for the ID. Instead, a group of oper-
or will change
[PgDn] [PgUp]
Nod e Name=n ode_xyz
from Main Menu
can be addresses, or (FRX6000/
FRX/FRM 3.3 User Guide, Rev 04
