Information in a Frame Relay Display
Information in a non-Frame Relay Display
17-28
is the number of frames transmitted/received with the DE (Discard
DE/sec (*10)
Eligibility) bit set per second over the five-second reporting
interval, multiplied by 10.
is the number of frames transmitted/received with the FECN
FECN/sec (*10)
(Forward Event Congestion Notification) bit set per second over
the five-second reporting interval, multiplied by 10.
is the number of frames transmitted/received with the BECN
BECN/sec (*10)
(Backward Event Congestion Notification) bit set per second over
the five-second reporting interval, multiplied by 10.
is the number of frames transmitted/received using LMI frame
LMI/sec (*10)
management per second over the five-second reporting interval,
multiplied by 10.
is the number of frames transmitted/received using Annex D frame
ANXD/sec (*10)
management per second over the five-second reporting interval,
multiplied by 10.
is the number of frames transmitted/received per second over the
Frames/sec (*10)
five-second reporting interval, multiplied by 10.
is the number of outgoing/incoming discarded frames per second
DiscF/sec (*10)
over the five-second reporting interval, multiplied by 10.
X.25 frame-level statistics are counts (per second, multiplied by 10) of these standard
LAPB commands and responses:
(set asynchronous balanced mode) (un-numbered command)
SABM
(un-numbered acknowledgment) (un-numbered response)
UA
(disconnect) (un-numbered command)
DISC
(disconnect mode) (un-numbered response)
DM
(frame reject) (un-numbered response)
FRMR
(reject) (supervisory command or response)
REJ
(receive ready) (supervisory command or response)
RR
(receive not ready) (supervisory command or response)
RNR
(information) (information transfer, command)
INFO
