Diagnostic Codes

X.25 Codes

D-4
These diagnostic codes are generated by the X.25 network in Clear, Reset, and Restart
Indication packets, as well as Registration Confirmation and diagnostic packets:
Hex. Dec. Description
No additional Information
00 00
Invalid P(s)
01 01
Invalid P(r)
02 02
Packet Type Invalid
10 16
Packet type Invalid for State r1
11 17
Packet type Invalid for State r2
12 18
Packet type Invalid for State r3
13 19
Packet type Invalid for State p1
14 20
Packet type Invalid for State p2
15 21
Packet type Invalid for State p3
16 22
Packet type Invalid for State p4
17 23
Packet type Invalid for State p5
18 24
Packet type Invalid for State p6
19 25
Packet type Invalid for State p7
1A 26
Packet type Invalid for State d1
1B 27
Packet type Invalid for State d2
1C 28
Packet type Invalid for State d3
1D 29
Packet not allowed
20 32
Unidentifiable packet
21 33
Call on one-way LCN
22 34
Invalid packet type on PVC
23 35
Packet on unassigned LCN
24 36
Reject not subscribed to
25 37
Packet too short
26 38
Packet too long
27 39
Invalid GFI
28 40
Restart with non-zero bits 1-4 in octet 1, or 1-8 in octet 2
29 41
Packet type not compatible with facility
2A 42
Unauthorized interrupt confirmation
2B 43
Unauthorized interrupt
2C 44
Unauthorized reject
2D 45
No channel available
2F 47
30 48 Time expired
Time expired for incoming call
31 49
Time expired for clear indication
32 50
33 51 Time expired for reset indication
Time expired for restart indication
34 52
(Restart Transfer Phase)
(Call Setup Phase)
(Call Clearing Phase)
(Reset during data xfer)
Packet Level Ready
DTE Restart Request
DCE Restart Indication
Ready
DTE Waiting
DCE Waiting
Data Transfer
Call Collision
DTE Clear Request
DCE Clear Indication
Flow control Ready
DTE Reset Request
DCE Reset Indication
FRX/FRM 3.3 User Guide, Rev 04
