Translation Template Parameters

Configuring X.25
The fields must match the equivalent fields in the Call Request packet, but not neces-
sarily literally—they can use wildcards.
Translation Temp late Maintenance
* LP
* Port
* Direction
* Temp late I D
A Temp late N ame
B Called Add ress
C User Data
D Calling Add ress
E Protocol ID
F Facilities
Option:
Figure 7-8 Address Translation Template Screen
Table 7-5 Translation Template Parameters
Parameter
1
Template Name
Called Address
Calling Address
User Data
Protocol ID
Facilities
Used simply for ease of identification.
1
These determine the translation formula:
2
= Pass through unchanged.
P
R = Remove entire field.
L = Replace with literal digit.
= Replace with original called address.
X
= Replace with original calling address.
G
U = Replace with original user data.
T = Replace with ASCII text.
If replacing all or part of a field, see "Replacing (field type)" over the next few pages.
Nod e Name=nod exyz
0
3
I
223*G19972U111154321*
tempexamp
P
D
L12345C23U 234
P
P
[A],[C],[D],[B] from Main Menu
Valid Values
0–31 characters
2
P,R,L,X,G,U
2
P,R,L,X,G,U
2
P,R,L,X,G,U,T
2
P , 0–8 characters
P ,R, 0–218 characters
Default Value
none
P
P
P
P
2
P
7-19
