FRX4000

Protocols

4-2
The Line Processor file contains this information for an FRX4000:
Amount of DRAM memory installed.
Type of Line Interface Card. (The serial expansion card in an FRX4000 is iden-
tical to the FRX6000 Line Interface Card.)
Configured and loaded protocols.
The terms "LP" and "RLP" are interchangeable.
To access the LP screens, press
To identify any installed Line Interface Card and display a list of configured and
installed protocols, press
protocols available in the node, press
When an FRX4000 is booted, the software reads the configuration of any installed
serial expansion card, as well as the amount of DRAM. This information will then be
read into the display.
For reference, the following figure shows the ports on an FRX4000.
Optional
LAN
CSU/DSU
Port
Port
WAN 4
WAN 0
Figure 4-1 Serial Ports on an FRX4000
To configure a protocol, press
an LP number, type
0 [Enter]
software that runs on an FRX6000 RLP also runs in the FRX4000, and the shared
software code requires configuring an LP in the FRX4000.)
, then from the Main Menu.
[A] [B]
at the LP Configuration Menu. (To display a list of all
[A]
, then
[A]
Ports 4–7 are on optional expansion module
WAN 5 WAN 6
WAN 1 WAN 2
[B] at the LP Configuration Menu. When prompted for
. (Although there is no LP in an FRX4000, much of the
, then from the Main Menu.)
[A] [G]
Console
Port
WAN 7
WAN 3
FRX/FRM 3.3 User Guide, Rev 04
