Displaying Virtual Connections

Information in this Display
Status and Statistics Displays
To display all physical and logical connections on a physical port, press
Status Displays Menu and, when prompted, enter the LP and physical port numbers.
The display will differ depending on whether or not the port is a frame relay port.
Figure 17-3 shows a frame relay port and Figure 17-4 shows a non-frame relay port.
Conn ection S tatus Disp lay Menu (Page 1) LP: 0 Port: 0
From:
SeqDLC I S tate
1 16 D ata_tran s
2 17 D ata_tran s
3 18 D ata_tran s
4 20 D ata_tran s
5 32 D ata_tran s
6 33 D ata_tran s
7 34 D ata_tran s
8 35 D ata_tran s
9 36 D ata_tran s
10 25 D ata_tran s
11 24 D ata_tran s
12 42 D ata_tran s
13 43 D ata_tran s
14 44 D ata_tran s
Figure 17-3 Virtual Connections Display on Frame Relay Port
is a sequence number used to identify the connection.
Seq
is the DLCI on which the connection exists.
DLCI
: means that call processing was successful and the connection
State Data_trans
is in the data transmission state.
means that the attached device is waiting for Call Accept.
Call_setup
Clearing means that the attached device is in Call Clear state, waiting for
Clear Confirmation.
means that a Reset has been sent to the remote device, and the
Resetting
attached device is waiting for a Reset Confirmation.
is self-explanatory.
Port_down
means that a connection has been established.
Connected
means that a connection has not been established or has been
Not_conect
broken.
C u m u l a t i v e To:
Tran s R ecd D is c LP P
587 497 0 1 9
588 574 0 1 10
592 586 1 1 11
580 486 0 1 14
585 602 6 1 18
600 594 0 1 19
621 600 0 1 22
579 543 0 1 23
586 584 0 1 24
588 586 4 1 30
593 610 0 1 29
602 498 5 1 33
610 506 0 1 34
585 560 0 1 35
Node N ame=node_xyz
DLCI State
16 Data_trans
17 Data_trans
18 Data_trans
20 Data_trans
28 Data_trans
29 Data_trans
30 Data_trans
31 Data_trans
32 Data_trans
25 Data_trans
24 Data_trans
42 Data_trans
43 Data_trans
44 Data_trans
[C],[C] from Main Menu
at the
[C]
