LP Parameters in an FRX6000
LP Type
Line Interface Card 1, 2
Protocol
Configuring Cards and Protocols
Table 4-3 FRX6000 Line Processor Parameters
Parameter
LP Type
Line Interface Card "n"
Protocol "n"
The size of each protocol and the amount of RLP memory determine the combinations
1
of protocols that can be configured on an RLP. (See explanation.)
Cannot be changed if the RLP is installed. If it is not installed, the value changes each
time you press
to select the parameter.
[A]
If you replace an LP or Line Interface Card with one of a dif-
ferent type, any related port records will have some invalid
values. Be sure to change them as needed.
contain the circuitry for the physical ports of an RLP. (LIC 1 contains ports 0–3, LIC
2 contains ports 4–7.) If the card is not installed, the value changes to the next one in
the list each time you press
the card installed, the software will read the LIC type, and this parameter cannot be
changed.
specifies which protocols will run on the RLP. When a new node is started up, X.25
will be loaded onto every RLP, and a software function called CONFIG will be loaded
onto the lowest-numbered RLP in the node. When you configure a new record, X.25
(and possibly CONFIG ) will already be displayed as installed. For each remaining
protocol, the available choices will be those protocols not already specified that will
fit on the RLP. (If you create a new record later for a new RLP, X.25 will be the only
available choice for Protocol 1.)
A 4MB RLP with CONFIG cannot contain any other protocols except
X.25.
Valid Values
None, RLP
None, RS-232, RS-422, V.35
None, X.25, Frame Relay, Async, SDLC,
BSC-I, BSC-B, IP, SNMP, RIP, LLC2, IPX,
NVSP, BRIDGE
to select the parameter. Once the node is booted with
[B]
Default Value
None
None
next in list not already
configured, among the
1
ones that will fit
4-9
