Configuring LLC2 Hosts

8-20
Each SNA/LLC2 host device that will connect to an FRX/FRM running LLC2 must
be configured in the database.
To display any LLC2 hosts already configured for this node, press
LAN Default Parameters Menu (or
the hosts' MAC addresses and identify each LLC2 session as
(In an Originated session, the host initiates LLC2 sessions; in a Terminated session,
the host accepts sessions destined for the address.)
A host-to-terminal connection is always initiated by the terminal.
To configure a host, press
prompted, enter:
Host Number:
0–128
Any other requested information (if this is a new host), noting Table 8-4 (on
page 8-22).The resulting display will depend on the configured session type:
Figure 8-6 = Originated, Figure 8-7 = Terminated.
SN A LLC2 Originated Sess ion Con figu ration (Screen 1 of 2)
* Host Nu mber: 1
A Host MAC Add ress
B S es sion Type
C T1 (100 ms ec)
D T2 (msec)
E Ti
F N 3
G Tw
H N 2
I Priority
J Ban dwidth A llocation Grou p
K R outing Sub scriber ID
L S ource MA C A ddress Mask
M C onnection s - Screen 2
Option:
Figure 8-6 LLC2 Originated Host Configuration Screen
Pressing
[M]
[A], [A], [E], [C]
at the Configure LAN Default Parameters Menu. When
[D]
. (Default is .)
0
0C005A 123402
Originated
10
100
30
1
1
8
0
1
1121000000*
40000470
[A],[A],[E],[D]
will display a screen similar to Figure 8-8.
at the Configure
[C]
from the Main Menu). This will list
or
Originated
Nod e Name=nod exyz
from Main Menu
FRX/FRM 3.3 User Guide, Rev 04
.
Terminated
