- Page 1 MMAC-Plus ™ Module Local Management 9G426-02 Module Specific Appendix 9032028...
-
Page 3: Modifying Fields And User Privileges
Appendix 9G426-02 Module Specific Information Introduction This appendix contains local management information that is specific to the 9G426-02 Ethernet Module. The 9G426-02 Ethernet Module is a 3-port switching module with: • 2 front panel gigabit Ethernet ports • 1 Internal Network Bus (INB) backplane port Modifying Fields and User Privileges To modify fields on this module, you must have read-write or super-user privileges. -
Page 4: Module Interface Codes
9G426-02 Module Specific Information Module Interface Codes The 9G426-02 Module has 7 interfaces. Table 1 lists the identifying number, name, and description of each interface. Table 1. 9G426-02 Module Interface Codes Interface Interface Interface Number Name Description SMB1 1 Mbps System Management Bus SMB10 10 Mbps System Management Bus HOST... -
Page 5: General Configuration Screen
9G426-02 Module Specific Information General Configuration Screen The General Configuration Screen (Figure 1), displays information about the selected module and allows you to set the following general parameters: • Module Date and Time • Screen Refresh and Lockout Time • Host IP Address •... -
Page 6: General Configuration Screen Fields
9G426-02 Module Specific Information General Configuration Screen Fields The following information briefly explains each General Configuration Screen field. Module Serial # Displays the serial number of the selected module. Module Board Revision Displays the version number of the selected module. FLASH Memory Displays the amount (megabytes) of flash memory in the selected module. - Page 7 9G426-02 Module Specific Information Screen Lockout Time Contains the maximum number of minutes that the Local Management application will display a module’s screen while pending input or action from a user. For example, if you enter 5 in this field, users will have up to five minutes to respond in some fashion to each of the specified module’s Local Management screens.
-
Page 8: Port Statistics Screen
9G426-02 Module Specific Information Port Statistics Screen The Port Statistics Screen (Figure 2), displays information and statistics about the module’s Ethernet ports. MMAC-Plus Local Management Port Statistics Module Name: 9G426-02 Firmware Revision: 01.00.00 Slot Number: 8 BOOTPROM Revision: 01.01.01 PORT #: 1 OCTETS: 471908210 LINK STATUS:... -
Page 9: Port Statistics Screen Fields
9G426-02 Module Specific Information Port Statistics Screen Fields The following information briefly explains each Port Statistics Screen field. PORT # Indicates the current port for which statistics are displayed. OCTETS Displays the number of octets transmitted and received on the port. PACKETS Displays the number of packets transmitted and received on the port. - Page 10 9G426-02 Module Specific Information MULTICASTS Displays the number of multicasts received. LINK STATUS Indicates whether there is a physical connection from this port to another device. One of the following values appears: • Link - There is a link signal present; there is a valid physical connection from this port to another device.
- Page 11 9G426-02 Module Specific Information Displaying Statistics for Another Port To display statistics for another port: 1. Use the arrow keys to highlight the Port # field at the bottom of the screen. 2. Press the Space Bar to increment (or press the Backspace key to decrement) the port number.
- Page 12 9G426-02 Module Specific Information...
