1.1.8

Port/VLAN Redirect Functions

The port redirect function, also referred to as "Port Mirroring," is a troubleshooting tool used to
map traffic from a single source port to a single destination port within the device. This feature
allows frames, including those with errors to be copied and sent to an analyzer or RMON probe.
The analyzer or RMON probe will see the data as if it were directly connected to the LAN segment
of the source port.
The VLAN redirect function is similar to the port redirect function except that the frames received
by the device are redirected to a designated destination port according to the VLAN classification
of the frames received. The VLAN redirect function does not support redirecting errors, and is
only supported when the device is operating as an 802.1Q switch. Multiple VLANs can be directed
to the same ports.
1.1.9

Rate Limiting

The Rate Limiting feature enables the SmartSwitch device to have control of traffic rates on a
per-port, per-priority basis. The network administrator can configure a rate limit (from 100 kbps to
1 Gbps) for a given port with an associated list of IEEE 802.1p priorities (which can include one,
some, or all of the eight priority levels defined in 802.1p). Each rate limit is specified as an
inbound or an outbound limit. The combined rate of all traffic on the port that matches the listed
priorities cannot exceed the programmed limit. If the rate exceeds the defined limit, frames are
dropped until the rate falls below the limit.
Administrators can configure up to four rate limit rules per port; however, each rule must not
include conflicting 802.1p priority values. In order to control traffic inbound and outbound on the
same port, two rate limit rules must be configured (one inbound and one outbound). Since the rate
limiting operation occurs after the processing of the multi-layer classification rules, the two
features can be combined to provide application-aware rate limiting.
This traffic rate function is not supported on ports configured as SmartTrunk ports.
NOTE NOTE NOTE NOTE
For more information about the application of the Rate Limiting function, refer to the Local
Management User's Guide.
