Configuring a Network Trunk

Configuring X.25
A network trunk is a link between FRX/FRM nodes, over X.25. Other ports in the
node can be assigned to a "trunk group," which will cause those ports to be disabled
if the network trunk is not operational (and enabled when the trunk becomes opera-
tional). One network trunk in a node can be assigned to another network trunk's group;
however, disabling/enabling a network trunk will not affect another network trunk in
that trunk's group.
X .25 Port Parameters (screen 5 of 6)
* RLP: 0 Port: 5 Link State: Linku p
* I/O: V.35
A Network Trun k
B Add to Tru nk Group
C Delete from Trun k Group
D Add a Range to Trunk Grou p
E Delete a Range from Tru nk Group
Ports A ssociated w ith Network Trunk
0 1
LP 0 N N
LP 1 N N
LP 2 N N
LP 3 N N
LP 4 N N
LP 5 N N
LP 6 N N
LP 7 N N
Option:
Figure 7-3 X.25 Port Trunk Parameters
LP 1–7 have no significance on an FRX4000 or FRM display.
If
Network Trunk
You can add or delete one or more ports as described in menu entries B–E in Figure
7-3. To add or delete a range of sequentially numbered ports (e.g., LP 1, port 3 through
LP 2, port 2) of the same port type, press
type, first LP and port, and last LP and port. The screen will be re-displayed, with the
status changed for each affected port.
Y/N
Adding or deleting a range has no affect on any port types within that range
other than the type specified.
To add or delete a single port, multiple ports that are not in sequence, or multiple ports
of different types, press
re-displayed, with the
Y/N
you want to add or delete.
Datab ase
Y
2 3 4 5 6
N N N N N
N N N N N
N N N N N
N Y Y Y N
N N N N N
N N N N N
N N N N N
N N N N N
is , the rest of the above screen has no relevance.
N
or
[D] [E]
or and enter an LP and port number. The screen will be
[B] [C]
status changed for the port. Repeat this process for each port
Nod e Name=n odexyz
7
N
N
N
N
N
N
N
N
and enter (when prompted) the port
7-11
