Cabletron Systems SmartSwitch 6000 User Manual page 167

Tw
N2
Priority
Bandwidth Allocation Group
Routing Subscriber ID
Source MAC Address Mask
Sq
HSAP
Local Subscriber ID
Configuring SNA
will be reset whenever an Information or Supervisory acknowledgment LPDU is
N3
sent by the local node.
is the maximum number of sequentially numbered Information LPDUs that the local
node can have outstanding. If
is the maximum number of times that an LPDU (including Information LPDUs resent
after a checkpoint operation) will be sent following expiration of
prioritizes intra-nodal traffic; the higher the number, the higher the priority. (This pri-
ority has no effect on traffic exiting a node.)
A priority is also configured in Node Defaults, as well as for each logical port, SNA
PU, Bridge port/LLC2 Interface, IP interface, IPX interface, SVC subscriber, and
PVC connection. The device processor in the node uses these priorities to help
determine the order in which it will process protocols.
When configuring priorities, be careful to consider the types of
traffic being routed on other connections in the node.
assigns the LLC2 host to one of sixteen groups whose parameters regulate bandwidth
usage. See "Configuring Bandwidth Allocation Groups" on page 6-6.
associates a Subscriber ID with the LLC2 host, and partially defines the local sub-
scriber IDs, all of which must begin with the
is used to identify the FRX/FRM to inbound frames from a local LAN in an Originated
LLC2 session. Source address masks and host MAC addresses are placed in a for-
warding list that is checked by the software when a frame is received. If the MAC
address in an incoming frame matches a configured Source MAC Address Mask, the
frame will be passed through the node for transmission out the frame relay interface.
is simply a sequence number to allow selection of a line in the display.
is the service access point (SAP) address used to connect to the host. This must match
the SSAP (source SAP) in a frame received from the local LAN or the DSAP (desti-
nation SAP) in a frame from the remote link station.
is the subscriber address assigned to the local end of the SNA connection. If config-
uring an LLC2-to-SDLC link, this address must match the
figured in the SNA port record for the SDLC device. If configuring an LLC2-to-LLC2
is reached, and acknowledgment will be sent.
Tw
Routing Subscriber ID
.
T1
.
con-
Remote Subscriber
8-25
