Displaying IPX RIP and SAP Tables

RIP Table

SAP Table

17-12
To display the contents of IPX RIP Table, press
Menu (or from the Main Menu). Each entry will contain the following:
[C], [F], [A]
is the IPX address of the network containing the FRX/FRM that con-
Network
tains the interface.
is the address of the router that will forward a packet when this route
Router Addr
is used.
is the number of routers in a packet's path to the destination network.
Hops
(Transport Time) is the time (in 55-millisecond units) that it will
TTime
normally take a packet to reach the destination network if this route
is used.
DNA (Do Not Age) identifies whether aging is enabled. (Aging allows
deletion of entries from the table after a specified period.) Routes
configured as static (see "Configuring Static IPX Routes" on page
12-16) will not age (
their IPX Interface records for the
All others will be
(Interface) is the time (in 55-millisecond units) that it will normally
Intf
take a packet to reach the destination network if this route is used.
The IPX RIP table displays data verbatim. Non-ASCII data might be dis-
played on some server types.
To display the contents of the SAP Table, press
Menu (or from the Main Menu). Each entry will contain the following:
[C], [F], [B]
Name is the name assigned to the server.
is the address of the router that will forward a packet when this route
Router Addr
is used.
is a SAP Service Type code, displayed in hex format. Some common
Type
codes are:
server).
(Intervening Networks) is the number of routers that a packet must
IntNw
pass through to reach the server if this route is used.
(Do Not Age) identifies whether aging is enabled. (Aging allows
DNA
deletion of entries from the table after a specified period.) Routes
configured as static (see "Configuring Static IPX Routes" on page
[A]
DNA = TRUE ). Interfaces with
.
FALSE
[B]
(print queue),
0003 0004
at the Protocol Status Displays
0 specified in
will also be
RIP Age Timer
at the Protocol Status Displays
(file server), and
0007
FRX/FRM 3.3 User Guide, Rev 04
.
TRUE
(print
