set rmon filter

C2(rw)->show rmon filter
Index= 55508
----------------------------------------------------------
Data Offset
PktStatusMask
Owner
-----------------------------
Data
ff ff ff ff ff ff
-----------------------------
DataMask
ff ff ff ff ff ff
-----------------------------
DataNotMask
00 00 00 00 00 00
set rmon filter
Use this command to configure an RMON filter entry.
Syntax
set rmon filter index channel-index [offset offset] [status status] [smask smask]
[snotmask snotmask] [data data] [dmask dmask] [dnotmask dnotmask] [owner owner]
Parameters
index
channel‐index
offset offset
status status
smask smask
snotmask snotmask
data data
dmask dmask
dnotmask dnotmask
owner
Defaults
If owner is not specified, it will be set to monitor.
If no other options are specified, none (0) will be applied.
15-20 RMON Configuration
Channel Index= 628
0 PktStatus
0 PktStatusNotMask
ETS,NAC-D
Specifies an index number for this entry. An entry will automatically be
created if an unused index number is chosen. Maximum number of
entries is 10. Maximum value is 65535.
Specifies the channel to which this filter will be applied.
(Optional) Specifies an offset from the beginning of the packet to look for
matches.
(Optional) Specifies packet status bits that are to be matched.
(Optional) Specifies the mask applied to status to indicate which bits are
significant.
(Optional) Specifies the inversion mask that indicates which bits should
be set or not set
(Optional) Specifies the data to be matched.
(Optional) Specifies the mask applied to data to indicate which bits are
significant.
(Optional) Specifies the inversion mask that indicates which bits should
be set or not set.
(Optional) Specifies the name of the entity that configured this entry.
EntryStatus= valid
0
0
