Port Mirroring
5. Enter MIB option 4 (createAndGo) and perform an SNMP Set operation.
6. (Optional) Use the CLI to verify the port mirroring instance has been created and enabled as
shown in the following example:
C2(su)->show port mirroring
Port Mirroring
==============
Source Port
Target Port
Frames Mirrored = Rx and Tx
Port Mirroring status enabled
To create a port mirroring instance without automatically enabling it:
1. Complete steps 1‐4 above.
2. Enter MIB option 5 (createAndWait) and perform an SNMP Set operation.
3. (Optional) Use the CLI to verify the port mirroring instance has been created set to disabled
mode as shown in the following example:
C2(su)->show port mirroring
Port Mirroring
==============
Source Port
Target Port
Frames Mirrored = Rx and Tx
Port Mirroring status disabled
4. When you are ready to enable this instance, enter MIB option 1 (active) and perform an SNMP
Set operation.
5. (Optional) Use the CLI to verify the port mirroring instance has been enabled.
To delete a port mirroring instance:
1. Select a previously created port mirroring instance in your MIB browser.
2. Enter MIB option 6 (destroy) and perform an SNMP Set operation.
3. (Optional) Use the CLI to verify the port mirroring instance has been deleted as shown in the
following example:
C2(su)->show port mirroring
No Port Mirrors configured.

Purpose

To review and configure port mirroring on the device.

Commands

For information about...
show port mirroring
set port mirroring
clear port mirroring
7-34 Port Configuration
= ge.1.3
= ge.1.2
= ge.1.3
= ge.1.2
Refer to page...
7-35
7-35
7-36
