Table 20-13 show ip pimsm staticrp Output Details
Output Field
Address
Group Address
Group Mask
show ip mroute
Use this command to display the IP multicast routing table.
Syntax
show ip mroute
Parameters
None.
Defaults
None.
Mode
Any router mode.
Usage
The multicast routing table shows how a multicast routing protocol, such as PIM and DVMRP,
will forward a multicast packet. Information in the table includes source network/mask and
upstream neighbors.
For information about DVMRP, see "Configuring DVMRP" on page 20‐33.
Example
This example shows the output of this command.
C2(su)->router#show ip mroute
Active IP Multicast Sources
Flags: D - Dense, S - Sparse, C - Connected, L - Local,P - Pruned, R - RP-bit set,
F - Register flag, T - SPT-bit set,Outgoing interface flags: H - Hardware switched
Timers: Uptime/Expires
Interface state: Interface, Next-Hop or VCD, State/Mode
Source Network
Source Mask
MultiCast Group
Uptime
Upstream Neighbor: 0.0.0.0
Upstream Vlan
Downstream Vlans : 8
Source Network
Source Mask
MultiCast Group
Uptime
What it displays
The IP address of the RP.
The group address supported by the RP.
The group mask for the group address.
: 192.168.111.10
: 0.0.0.0
: 239.1.8.9
: 6336
: 111
: 192.168.111.10
: 0.0.0.0
: 239.1.7.105
: 6336
SecureStack C2 Configuration Guide 20-59
show ip mroute
