Port Configuration Summary
• Four SFP slots that provide the option of installing Small Form Pluggable (SFP) Mini‐GBICs
for 1000BASE‐T compliant copper connections or 1000BASE‐SX\LX\ELX fiber‐optic
connections.

C2G134-24P Switch Ports

The C2G134‐24P stackable devices provide the following types of switch port connections:
• Twenty‐four 10/100/1000 Mbps 1000BASE‐T Fast Ethernet copper ports connected through
four RJ21 connectors (six ports per RJ21).
• Four SFP slots that provide the option of installing Small Form Pluggable (SFP) Mini‐GBICs
for 1000BASE‐T compliant copper connections or 1000BASE‐SX\LX\ELX fiber‐optic
connections.

C2K122-24 Switch Ports

The C2K122‐24 stackable devices provide the following types of switch port connections:
• Twenty‐four RJ45 10/100/1000 Mbps 1000BASE‐T Fast Ethernet copper ports
• Two XFP slots that provide the option of installing XFP MSA‐compliant modules for 10‐
Gigabit, 10GBASE‐L/‐LR/‐ER fiber‐optic connections.

C2G170-24 Switch Ports

The C2G170‐24 stackable devices provide the following types of switch port connections:
• Twenty‐four SFP slots that provide the option of installing Small Form Pluggable (SFP) Mini‐
GBICs for 1000BASE‐T compliant copper connections or 1000BASE‐SX\LX\ELX.
Important Notice About C2G1x4-xx 10/100/100 and SFP Mini-GBIC Ports
SFP Mini-GBIC uplink ports are used in an either / or configuration with the C2 front panel RJ45 10/100/1000
Mbps 1000BASE-T Fast Ethernet copper ports. If all Mini-GBIC ports are used, four of the RJ45 ports will be
disabled. The maximum number of active ports can be 24 on the C2G124-24, and 48 on the C2G124-48 and
C2G124-48P, in any combination of RJ45s and Mini-GBICs.

Port String Syntax Used in the CLI

Commands requiring a port‐string parameter use the following syntax to designate port type, slot
location, and port number:
port type.unit_or_slot number.port number
Where port type can be:
fe for 100‐Mbps Ethernet
ge for 1‐Gbps Ethernet
tg for 10‐Gbps Ethernet
host for the host port
vlan for vlan interfaces
lag for IEEE802.3 link aggregation ports
Where unit_or_slotnumber can be:
1 ‐ 8 for switch units in a stack
7-2 Port Configuration
