4. In the CoS settings table, configure a CoS setting for CoS index 1, which has a priority of 0. We
enter the IRL reference, created in the previous step.
C2(su)->set cos settings 0 irl-reference 1
C2(su)->show cos settings
CoS Index Priority
--------- ---------- ------- -----
0
1
2
3
4
5
6
7

About CoS-Based Flood Control

Co
Note: CoS-based flood control does not require a policy license on SecureStack B2 and B3
switches or on standalone D2 switches.
CoS‐based flood control prevents configured ports from being disrupted by a traffic storm by rate‐
limiting specific types of packets through those ports. When flood control is enabled on a port,
incoming traffic is monitored over one second intervals. During an interval, the incoming traffic
level for each configured traffic type is compared with the configured traffic storm control level,
specified as a percentage of the total available bandwidth of the link. The default threshold is 5%
of link speed.
If, during a one second interval, the incoming traffic of a configured type reaches the traffic storm
control level configured on the port, CoS‐based flood control drops the traffic until the interval
ends. Packets are then allowed to flow again until the limit is again reached.
The following procedure describes the steps and commands required to configure CoS‐based
flood control.
Procedure 11-2
Step Task
1. Enable CoS.
2. Create a CoS flood control port resource, which
specifies flood control rate limiters that can be
mapped to specific ports.
3. Assign the flood control resource to specific
ports.
Example
This example creates a broadcast rate limiter (index 1.0) of 5 packets per second and assigns it to
ports ge.1.2 and ge.2.2.
2 irl none
3 irl none
97 irl none
98 irl none
99 irl none
ToS IRL
0 *
1 *
2 *
3 *
4 *
5 *
6 *
7 *
Configuring Policy Class of Service (CoS)
1
*
*
*
*
*
*
*
Command(s)
set cos state enable
set cos port-resource flood-ctrl
set cos port-config flood-ctrl
SecureStack C2 Configuration Guide 11-19
