How To Remove / Re-Install The Top Access Door - Magtek ExpressCard 2000 Hardware Service Manual

5 - Removal and Re-installation
5.5

How to Remove / Re-install the Top Access Door

Approximate time to remove: 5 minutes plus any sub-procedures
Approximate time to re-install: 5 minutes plus any sub-procedures
Some of the modules inside the ExpressCard you are servicing may look different from
the photos in this procedure. However, the steps of the procedure are the same, and are
unrelated to / unaffected by the appearance of the modules.
The top access door is the large lockable door in the top of the cover that secures the user-serviceable
areas inside the device, while allowing users to access and replace consumable items like image printer
ribbons and card stock. Some service procedures require removing the top access door to give
unobstructed access to certain components.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Figure 5-24 - Top Access Door (REAR VIEW)
Page 94 of 356 (D99875607-91)
