5 - Removal and Re-installation
24) Carefully unthread the
cable from its routing path to free it
HOPPER SHUTTLE HOME SENSOR
completely from the device, leaving it connected to the rear of the hopper transport module.
25) Gently push the hopper shuttle to the middle of the device.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 120 of 356 (D99875607-91)
