5 - Removal and Re-installation
The tipper heater is hot and can burn your skin! Make sure the device has been turned
off, or the heater has been turned off and no cards have been produced, for at least 10
minutes to allow adequate cooling time before touching the tipper heater.
Some of the modules inside the ExpressCard you are servicing may look different from
the photos in this procedure. However, the steps of the procedure are the same, and are
unrelated to / unaffected by the appearance of the modules.
The tipper module receives cards from the exit transport module, stamps them with heat-fused foil from
the tipper foil roll, then moves them to the card output bin on a cushion of air. It is located in the front
middle of the top deck plate, just to the rear of the card output bin.
