5 - Removal and Re-installation
Figure 5-170 - Indent the Metal on the Right Side of the Ethernet Jack (REAR VIEW)
Figure 5-171 - Use the Slotted Screwdriver to Release the Black Clip (REAR VIEW)
11) Ease Ethernet jack into the ExpressCard case through the mounting hole (see Figure 5-172).
Figure 5-172 - Pull the Ethernet Jack Into the Case (REAR LEFT VIEW)
12) Carefully thread the cable out of the device through the left side access door, making sure not to let it
get hung up on anything inside the device.
