6 - Adjustments
6.5.3 How to Calibrate XY Transport to Exit Transport Handoff
To calibrate where the XY Transport goes to push a card into the exit rollers, follow these steps:
1) Make sure you have moved a card to the XY Transport as described in the previous section.
2) Navigate to
Menu
>
page.
3) Press the
XY To Embosser
4) Press the
XY To Exit
5) Make sure the XY Transport does not bump against the Exit Transport.
6) Make sure the first green roller on the exit ramp is centered on the card.
7) Make sure the card is pushed into the exit ramp past the point where the first green roller touches it.
8) If the card doesn't fit all three of these conditions, adjust the handoff location by following these
steps:
a) Navigate to
Menu
password page.
b) Enter password
c) Enter password
d) Scroll down in the list of settings until you find the ExitHandoffAdjustmentX setting.
e) If the XY Transport bumped into the Exit Transport, decrease the ExitHandoffAdjustmentX
setting by selecting the number in the list, pressing the
on the on-screen keypad and pressing the
f) If the card did not push far enough into the exit ramp, increase the ExitHandoffAdjustmentX
setting by selecting the number in the list, pressing the
on the on-screen keypad and pressing the
g) If the card is off-center from the green roller and is too close to the front of the device, increase
the ExitHandoffAdjustmentY setting by clicking the number in the list, pressing the
then entering the new number on the on-screen keypad and pressing the
10 steps at a time.
h) If the card is off-center from the green roller and is too close to the back of the device, decrease
the ExitHandoffAdjustmentY setting by clicking the number in the list, pressing the
then entering the new number on the on-screen keypad and pressing the
10 steps at a time.
i) Press the
Save
j) Repeat these steps from step 1 until the card clamps correctly when it exits the printer.
9) Navigate to
>
Menu
page.
10) Press the
Unclamp Card
11) Press the
Exit Eject
12) Press the
Status
button to return to the Status page.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Settings
>
Service
>
button.
button.
>
Settings
>
Edit Config
and press the
1234567
7654321
to open the
Configuration Editing
button to save your changes.
>
>
Settings
Service
button to release the card.
button to eject the card into the card output bin.
Page 334 of 356 (D99875607-91)
MCP Commands
to open the
to open the first
button to open the second password page.
E
page.
C
button, then entering the new number
button. Adjust about 10 steps at a time.
E
button, then entering the new number
C
E
button. Adjust about 10 steps at a time.
to open the
MCP Commands
Controller Commands
Configuration Editing
C
button. Adjust about
E
C
E
button. Adjust about
Controller Commands
button,
button,
