6 - Adjustments
6.2.2 How to Calibrate Hopper Transport Manual Feed Slot to Printer Handoff
To calibrate the Y position of the Hopper shuttle during handoff to the printer (from the manual feed slot),
follow these steps
1) Make sure hopper 2 and hopper 3 are removed.
2) On the touchscreen, navigate to
Controller Commands
3) Press the
Shuttle Home
4) Press the To Manual Feed
5) Insert a blank card into the manual feed slot with its magnetic stripe facing down and to the right.
The slot will not automatically take the card.
6) Press the
Roller Consume
7) Press the Shuttle to Printer
access door.
8) Check to make sure the card is centered at the opening of the image printer.
9) If the card is centered at the printer opening, press the
10) If the card is not centered at the printer opening or if it hit either side of the printer opening or if the
card skewed to one side when entering the printer:
a) Pull on the triangular belt on the front side of the hopper shuttle to back the card out of the hopper
shuttle, and remove the card.
b) Inspect the hopper drive belt and make sure it is tight. A loose drive belt can slip and cause the
hopper transport to not move as far as the device thinks it is moving. If you discover the drive
belt is loose, stop and contact MagTek Support Services for help.
c) Navigate to Menu
page.
d) Enter password
e) Enter password
f) Scroll through the list of options to find the ShuttleHomeToExceptionFeed setting, and select
the number beneath it to bring up the on-screen keypad.
g) If hopper shuttle was too far toward the rear of the device, decrease the setting, press the
button, and to back to the beginning of this section.
h) If hopper shuttle was too far toward the front of the device, increase the setting, press the
button, and go back to the beginning of this section.
11) Press the
Printer Eject
12) Remove the card from the image printer exit and recycle it.
13) Re-install hopper 2 and hopper 3 in the device.
14) Press the button to return to the
Status
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Menu > Settings
page.
button.
button.
button.
button. If you need a better view of the card, open the image printer top
> Settings > Edit Config.
1234567 , then press the
, then press the
7654321
button.
Status
Page 324 of 356 (D99875607-91)
> Service > MCP Commands
Roll to Printer
to open the Configuration Editing
E button.
button to open the
E Configuration Editing
page.
to open the
button.
password
page.
Save
Save
