6 - Adjustments
6.5
How to Calibrate the XY Transport Module
6.5.1 About Calibrating the XY Transport
There are two settings that must be calibrated to make sure cards are properly handed off from the image
printer to the XY transport. Each setting represents the number of steps the XY motors should take to get
to the specified location.
The
PrinterHandoffAdjustmentX
device (the X direction) it should move its carriage to pick up cards from the image printer.
The
PrinterHandoffAdjustmentY
the device (the Y direction) it should park to take cards from the image printer. The XY transport
should be far enough forward that cards coming out of the image printer slide into its card clamp and
push the spring-loaded rail (the "justifier") at the printer exit a short distance (0.04" to 0.06") toward
the front of the device. This pressure allows the justifier to straighten the card against the XY
transport's card clamp.
If the XY transport needs to be calibrated, follow the steps in this section.
6.5.2 How to Calibrate Printer to XY Transport Handoff
To calibrate where the XY transport goes to take a card from the printer, follow these steps:
1) Navigate to
>
Menu
page.
2) Press the
Pusher Home
3) Press the
Shuttle Home
4) Next to the "To Hopper" button, select
5) Press the
Push To Roller
6) Press the
Shuttle To Printer
7) Press the
XY Home
8) Press the
XY To Printer
9) Press the
XY To Printer In
10) Press the
Unclamp Card
11) Press the
Roll To Printer
12) Press the
Printer Eject
13) Press the
Clamp Card
14) Make sure the card reaches far enough out of the printer that sticks out just past the second metal
block on the card clamp assembly (both metal blocks are circled in Figure 6-2).
15) Make sure the card touches the back of the black plastic part of the card clamp all along the line
shown in Figure 6-2.
16) Make sure the card is pushed far enough toward the front of the device that it pushes on and raises the
metal justifier flag next to the printer exit (even just a little bit is OK).
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
setting tells the XY transport how far toward the right of the
setting tells the XY transport how far toward the front or rear of
>
>
Settings
Service
button.
button.
1
from the list and press the
button.
button.
button.
button.
button.
button.
button.
button.
button.
Page 332 of 356 (D99875607-91)
to open the
MCP Commands
To Hopper
Controller Commands
button.
