5 - Removal and Re-installation

5.29 How to Remove / Re-install the Embedded PC Solid State Drive (SSD)

Approximate time to remove: 5 minutes plus any sub-procedures
Approximate time to re-install: 5 minutes plus any sub-procedures
The embedded PC's solid state drive (SSD) contains its operating system and software. It is mounted to
the embedded PC in the rear right corner of the lower deck ("tub") of the device.

5.29.1 Tools, Materials, and Documents

Part Number
Required
N/A
N/A
N/A
Suggested
33011008
33011009
N/A
N/A
N/A
N/A
N/A
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Quantity
1 ea. No. 1 Phillips screwdriver
N/A Access to telephone
1 ea. Tools, materials, and documents required for sub-procedures
1 ea. ASM TOOL KIT, FIELD SERVICE, EC2000, EC3000
ASSEMBLY, FIELD SERVICE KIT, SPARE PARTS STARTER,
1 ea.
EC2000, EC3000
1 ea. Long tool for moving wires inside lower deck
1 ea. Flashlight or equivalent
1 ea. Pen or pencil
1 ea. Paper and clipboard
1 ea. Digital camera or smartphone with camera
