5 - Removal and Re-installation
5.4.3 Re-install
Follow these steps to re-install the right side cover:
1) Reverse the last few steps to re-attach the new right side cover to the whole cover.
2) Re-install the touchscreen in the cover (see section 5.36).
3) Re-install the whole cover on the device (see section 5.3).
4) Re-install the magnetic stripe reader in the device (see section 5.35).
5) Re-install the top access door on the device (see section 5.5).
6) Complete any other service that requires the device to be powered off and open.
7) Power on the device and test it, paying special attention to the following:
a) Test the touchscreen and manual feed slot light and functionality by creating a sample card from
the manual feed slot using the touchscreen.
b) Make sure the device shows
c) Test the electronic latches by testing the remote unlock function.
8) If the device does not power on or function properly, contact MagTek Support Services for assistance
(see Appendix A Technical Support).
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
on the
Offline
Status
Page 93 of 356 (D99875607-91)
page when the top access door is open.
