Magtek ExpressCard 2000 Hardware Service Manual page 229

5 - Removal and Re-installation
The tipper heater is hot and can burn your skin! Make sure the device has been turned
off, or the heater has been turned off and no cards have been produced, for at least 10
minutes to allow adequate cooling time before touching the tipper heater.
Some of the modules inside the ExpressCard you are servicing may look different from
the photos in this procedure. However, the steps of the procedure are the same, and are
unrelated to / unaffected by the appearance of the modules.
The exit transport module takes cards from the XY transport module after embossing, and moves them
either to the card rejection bin or to the tipper and exit ramp. It includes an integrated MagnePrint reader,
which can optionally be used to read each issued card's magnetic stripe and produce a digital identifier
(DI) for later validation that the card is genuine and that its encoded data has not been altered. The exit
transport is attached to the center of the device's top deck plate.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 229 of 356 (D99875607-91)
