5 - Removal and Re-installation
6) Reach into the left side access door and push the AC filter through the case until it hangs freely
outside the case (see Figure 5-155). If the cable is not long enough to expose the connectors outside
the case as shown, use the wire cutters or diagonal side cutters to carefully cut the cable tie that
anchors the cable to the bottom of the case.
7) Disconnect the cable from the AC filter. If the connectors are tight, loosen them by wiggling them
from side to side while pulling on the connector.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Figure 5-154 - AC Filter Inside Case
Figure 5-155 - AC Filter Removed from Case, Still Wired
