3 - Preventive Maintenance Procedure (EC2000)
Figure 3-3 - Cleaning the Right Side of the Exit Transport (TOP VIEW FROM FRONT)
d) Feed the cleaning card partly under the exit ramp rollers and press the
the card there until the rollers stop moving.
Figure 3-4 - Cleaning the Exit Ramp Rollers (TOP VIEW FROM FRONT)
5) Press the Status button to return to the
6) Re-install the tipper foil cartridge with the original tipper foil roll, or obtain and install a new one
from the customer.
7) Re-install hoppers 1 and 2.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Status page.
Page 40 of 356 (D99875607-91)
button. Hold
Exit Eject
