5 - Removal and Re-installation
7) Use the No. 2 Phillips screwdriver to loosen the screws that secure the three power input wires to the
power supply, then disconnect the wires.
8) Unplug the white plastic power supply control and monitoring connector shown in Figure 5-163.
Figure 5-163 - Power Supply Control and Monitoring Connector (LEFT VIEW)
9) Use the No. 2 Phillips screwdriver to loosen the screws holding the power supply output cables, then
disconnect the cables. See Figure 5-164.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Figure 5-162 - Power Supply Input Wires (LEFT VIEW)
