2 - Introduction
1) Verify the ExpressCard software supports the character(s) you are going to install.
2) Look at the numbers stamped on each embosser wheel tine to find the number of the tine where you
will install the new character.
3) Install the character on the tine. Every character has a piece on the top embosser wheel and a second
piece on the bottom embosser wheel, so make sure to install both, and to put each piece on the correct
half: For embossing fonts and rear indent fonts (FontID1, FontID2, and FontID4), the "punch"
(positive) side goes on the bottom; for front indent fonts (FontID3), the "punch" side goes on the top.
Indent fonts have a "blank" flat side that goes opposite the punch side.
4) Install both halves of the character on the new tine.
5) On the touchscreen, navigate to
Character Mapping
6) Enter password
4567890
page.
7) Enter password 0987654
8) Use the
Add Char.
installing a capital 'A,' select 65). Verify you have selected the character you expected to select by
looking at the
ASCII Char
9) Use the dropdown list to indicate the type of font you have installed (FontID1-4).
Font
10) Use the dropdown list to select which tine you have installed the characters on.
To
11) Press the button.
Add
12) Repeat the above steps for any additional characters you need to add.
13) Test your changes by creating a sample card or an embosser tuning card.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
>
Menu Settings
password page.
, then press the key to open the second
E
, then press the E key to open the
dropdown list to select what character you are installing (for example, if you are
box next to the dropdown list.
Page 35 of 356 (D99875607-91)
> >
Service Char Map
Character Mapping
Character Mapping
to open the first
password
page.
