2 - Introduction
Press This Button
Top Cartridge Home
Indenter Move
Top Cart to Indent Loc.
Indenter Move
Top Ribbon Advance
Indenter Move
Roller Consume
Push To Roller
Shuttle To Printer
Roll To Printer
XY Home
XY Home X
XY Home Y
XY To Printer
XY To Printer In
Unclamp Card
Printer Eject
Clamp Card
Embosser Home
Wheel Home
XY To Embosser
CardHomeXY
XY To Exit
Unclamp Card
Exit Reject
Exit Eject
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
,
Only if testing ExpressCard with Front Indenter installed:
Front (white) indent cartridge moves back into (or stays in) embosser
,
Only if testing ExpressCard with Front Indenter installed:
Front (white) indent cartridge moves between letters on embosser wheel
,
Only if testing ExpressCard with Front Indenter installed:
Ribbon in front (white) indent cartridge advances by about ¼"
Hopper shuttle's wheels turn for a few seconds
Hopper shuttle takes a card from current hopper
Hopper shuttle moves to image printer
Hopper shuttle's wheels turn for a few seconds to feed card into image
printer. Press
Printer Eject
XY Transport moves to rear left of device
XY Transport's X carriage moves to the left
XY Transport's Y transport moves to the rear of the device
XY Transport moves to image printer
XY Transport's X carriage moves toward image printer to engage with card
X carriage's card clamp rotates to unclamped position
Card at image printer input is ejected to image printer exit
X carriage clamps card at printer exit
Embosser wheel moves to first character on wheel (look for empty tines
next to the tine that is currently between the hammers)
Embosser hammers open completely (not squeezing embosser tines)
Embosser wheel moves to first character on wheel (look for empty tines
next to the tine that is currently between the hammers)
XY Transport moves card out of printer and to embosser
XY Transport moves card so its lower left corner is between embosser tines
XY Transport moves card to Exit Transport's input rollers
X carriage's clamp releases the card
Exit transport raises its bottom roller, rolls for a short period of time. Ramp
fan turns on. Card goes into Card Rejection Bin.
Exit Transport rolls card to exit ramp, ramp fan turns on briefly.
Page 26 of 356 (D99875607-91)
Verify This Happens
button to move card through image printer.
