5 - Removal and Re-installation

5.21.2 Unpack

To safely unpack the replacement embosser module, follow these steps:
1) Place the embosser on a sturdy work surface.
2) Turn the embosser box upside down so the side with the exposed bolt heads faces the ceiling, as
shown in Figure 5-78.
Figure 5-78 - Position of Replacement Embosser Box to Open Safely
3) Use the medium or large slotted screwdriver to raise and straighten the four tabs around the top edges
of the box as shown in Figure 5-79.
4) Carefully lift the embosser out of the box as shown in Figure 5-80. Turn it upside down so the
embosser is facing up, and set it on a sturdy work surface.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Figure 5-79 - Opening Tabs on Replacement Embosser Box
Page 216 of 356 (D99875607-91)
