5 - Removal and Re-installation
15) Re-clip any cables you moved for easier access during removal.
16) If you disconnected the hopper shuttle motor cable, re-connect it and tie wrap the two cables back to
the motor plate, as they were before you disconnected them.
17) Remove the right side access door to gain access to the embedded PC (for reference, see section 5.7
How to Remove / Re-install the Side Access Doors).
18) Connect a USB keyboard to a spare USB port on the embedded PC.
19) Re-connect the power cable to the back right of the image printer.
