5 - Removal and Re-installation
25) Tuck the
HOPPER SHUTTLE EXC HOME SENSOR
circuit board to prevent it from snagging on moving parts.
26) Clip the
HOPPER SHUTTLE EXC HOME SENSOR
the device, and take up any slack along its length.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
cable underneath the
cable into the cable clip along the right wall of
Page 134 of 356 (D99875607-91)
HOPPER SHUTTLE
