5 - Removal and Re-installation
13) Use the 1/8" hex wrench to remove the three screws securing the XY transport to the top deck plate
near the front of the device (see Figure 5-64) and set them aside.
14) Use both hands on the rails to carefully lift the XY transport module out of the device, making sure
no cables catch on any other modules, and set it aside.
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 204 of 356 (D99875607-91)
