5 - Removal and Re-installation
18) Plug the
HOPPER SHUTTLE HOME SENSOR
HOPPER SHUTTLE
19) Use cable ties 89800023 and 89800006 at the locations shown to tie the
cable to the bundle of cables. Use wire cutters or a cable tie tool to trim the ties.
SENSOR
ExpressCard 2000 / ExpressCard 3000| Instant Issuance Card Personalization System | Hardware Service Manual
circuit board.
Page 131 of 356 (D99875607-91)
cable into the
J3 HOME SENS
HOPPER SHUTTLE HOME
connector on the
