6 - Adjustments
6.3 How to Calibrate the Image Printer Module
These steps may be necessary after installing a new image printer or after installing software, firmware, or
driver updates.
6.3.1 About Calibrating the Image Printer
ExpressCard provides options to configure the image printer. Settings include how it prints, whether it
includes lamination ("Overlay") on each side of the card, the stretching and position of images, the fonts
it uses to print each embossed Font ID, and so on.
6.3.2 How to Set Ribbon and Driver Settings
To set the image printer to factory settings, follow these steps:
1) Install a YMCKO ribbon (see the ExpressCard 2000 Installation and Operation Manual).
2) On the touchscreen, navigate to
3) Press the Auto Detect & Configure Ribbon
the button until the process is complete.
4) When the device pops up a window reporting
press the
configured
5) Press the
Advanced
