How to Programme

2.2.8 Main Menu Mode

2 2 Start the Main Menu mode by pressing [Main Menu]. The
read-out shown below appears on the display.
The middle and bottom sections on the display show a list
of parameter groups which can be chosen by toggling [
▼
and [ ] keys.
Illustration 2.10
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu.
However, depending on the choice of configuration
(1-00 Configuration Mode), some parameters can be
"missing". E.g. open loop hides all the PID parameters, and
other enabled options make more parameter groups
visible.

2.2.9 Parameter Selection

In the Main menu mode, the parameters are divided into
groups. Select a parameter group with the navigation keys.
The following parameter groups are accessible:
Group no. Parameter group
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** References/Ramps
4-** Limits/Warnings
5-** Digital In/Out
6-** Analog In/Out
7-** Controls
8-** Comm. and Options
9-** Profibus
10-** CAN Fieldbus
11-** Reserved Com. 1
12-** Reserved Com. 2
13-** Smart Logic
14-** Special Functions
15-** Drive Information
18
®
VLT AQUA Drive Programming Guide
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
MG20O602 - VLT
Group no. Parameter group
16-** Data Readouts
17-** Motor Feedb. Option
18-** Data Readouts 2
30-** Special Features
▲
]
32-** MCO Basic Settings
33-** MCO Adv. Settings
34-** MCO Data Readouts
1 (1)
Table 2.5
After selecting a parameter group, choose a parameter by
means of the navigation keys.
The middle section on the display shows the parameter
number and name as well as the selected parameter value.
Illustration 2.11

2.2.10 Changing Data

The procedure for changing data is the same in the Quick
menu and the Main menu mode. Press [OK] to change the
selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.

2.2.11 Changing a Text Value

If the selected parameter is a text value, change the text
▲
value with the [
Place the cursor on the value to save and press [OK].
Illustration 2.12
®
is a registered Danfoss trademark
740RPM 10.64A
Basic Settings
0 -01 Language
[0] English
▼
] [ ] keys.
740RPM 10.64 A
Basic Settings
0 -01 Language
[0] English
1 [1]
0-0 *
1 [1]
0-0 *
