 3-line monitor setting
On the operation panel or parameter unit, the 3-line monitor is used as the first monitor.
 Direct setting
Pressing the [FUNC] key on the FR-PU07-01 displays the direct setting screen. The PID action set point can be directly set
regardless of the operation mode or Pr.77 Parameter write selection setting.
Pressing the [FUNC] key on the direct setting screen displays the function menu.
Direct setting
Direct setting 1
Direct setting 2
 Dedicated parameter list function
Pressing the [PrSET] key of the FR-PU07-01 displays the dedicated parameter list. Parameters that need to be set first for the
PID extended display setting are listed.
Dedicated parameter list
No.1
No.2
No.3
NOTE
• The display of parameters other than the above may be changed due to changes in C42 or C44. Set the PID monitor indicator
before changing the settings of other parameters.
• To use the direct setting on the LCD operation panel, set Pr.1000Direct setting selection. (Refer to
 GOT initial setting (PU connector) (Pr.999 = "10, 12")
Pr. Name
79 Operation mode selection
118 PU communication speed
PU communication stop bit length / data
119
length
120 PU communication parity check
121 PU communication retry count
122 PU communication check time interval
123 PU communication waiting time setting
124 PU communication CR/LF selection
340 Communication startup mode selection
414 PLC function operation selection
*1 When Pr.414 = "1", the setting value is not changed.
 Initial setting with the GOT2000 series
• When "FREQROL 500/700/800, SENSORLESS SERVO" is selected for "Controller Type" in the GOT setting, set Pr.999
= "10" to configure the GOT initial setting.
• When "FREQROL 800(Automatic Negotiation)" is selected for "Controller Type" in the GOT setting, the GOT automatic
connection can be used. When "FREQROL 800(Automatic Negotiation)" is selected for "Controller Type" in the GOT
setting and the GOT automatic connection is not used, set Pr.999 = "12" to configure the GOT initial setting. (Refer to
667.)
 Initial setting with the GOT1000 series
• Set Pr.999 = "10" to configure the GOT initial setting.
NOTE
• Always perform an inverter reset after the initial setting.
• For the details of connection with GOT, refer to the Instruction Manual of GOT.
Parameter to be set
Pr.133 PID action set point
Pr.755 Second PID action set point
Parameter to be set
Pr.999 Automatic parameter setting
Pr.934 PID display bias coefficient
Pr.935 PID display bias analog value
Initial value
0
192
1
2
1
9999
9999
1
0
0
Pr.999 = "10" Pr.999 = "12"
1 1
192 1152
10 0
1 1
9999 9999
9999 9999
0 ms 0 ms
1 1
0 0
*1
—
2
5.7 (E) Environment setting parameters
page 323.)
Refer to page
370
636
378
614
page
335
