WHEEL BEARING
Turn the inner race of each bearing with your finger.
The bearings should turn smoothly and quietly.
Also check that the bearing outer race fits tightly in
the hub.
Remove and discard the bearings if the races do not
Replace the wheel
turn smoothly, quietly, or if they fit loosely in the
bearings in pairs.
hub.
WHEEL BALANCE
• Wheel balance directly affects the stability, han-
dling and over all safety of the scooter. Always
check balance when the tire has been removed
from the rim.
• For optimum balance, the tire balance mark (a
paint dot on the side wall) must be located next
to the valve stem. Remount the tire if necessary.
Note the rotating direction mark on the tire.
When Install the tire by aligning the balance mark of
the tire and valve stem of the rim within 50 mm (2.0
in).
Remove the dust seals from the wheel.
Mount the wheel, tire and brake disc assembly in an
inspection stand.
Spin the wheel, allow it to stop, and mark the lowest
(heaviest) point of the wheel with a chalk.
Do this two or three times to verify the heaviest
area.
If the wheel is balanced, it will not stop consistently
in the same position.
To balance the wheel, install the wheel weights on
the highest side of the rim, the side opposite the
chalk marks. Add just enough weight so the wheel
will no longer stop in the same position when it is
spun. Do not add more than 70 g (2.5 oz) to the
wheel.
DISASSEMBLY
Remove the front pulsar ring (page 18-25).
NSS250A:
Remove the socket bolts and brake disc.
Remove the dust seal.
maxiscooter-club.ru
FRONT WHEEL/SUSPENSION/STEERING
NSS250A shown:
ROTATING
DIRECTION MARK
VALVE STEM
NSS250A shown:
INSPECTION STAND
DUST SEAL
SOCKET BOLTS
BALANCE MARK
BRAKE DISC
15-15
