Introduction

1 Introduction

1.1 Purpose of the Manual

This manual provides the information required to install
and set up communication using BACnet protocol.
First-time users can obtain the most essential information
for quick installation and set-up in these chapters
chapter 1 Introduction
chapter 3 Installation
chapter 4 System Configuration
For more detailed information including the full range of
set-up options and diagnosis tools refer to the chapters:
chapter 6 Parameters
chapter 7 Troubleshooting
®
VLT is a registered trademark.

1.2 Additional Resources

Literature available:
•
®
VLT DriveMotor FCP 106 and FCM 106 Operating
Instructions, for information required to install and
commission the frequency converter.
•
®
VLT DriveMotor FCP 106 and FCM 106 Design
Guide, provides information required for
integration of the frequency converter into a
diversity of applications.
•
®
VLT DriveMotor FCP 106 and FCM 106
Programming Guide, for how to program the unit,
including complete parameter descriptions.
•
®
VLT LCP Instruction, for operation of the local
control panel (LCP).
•
®
VLT LOP Instruction, for operation of the local
operation pad (LOP).
•
Modbus RTU Operating Instructions, Operating
®
Instructions VLT DriveMotor FCP 106 and FCM 106
BACnet and Operating Instructions VLT
FCP 106 and FCM 106 Metasys, for information
required for controlling, monitoring, and
programming the frequency converter.
•
PC-based Configuration Tool MCT 10, enables
configuration of the frequency converter from a
Windows™ based PC environment.
•
®
Danfoss VLT Energy Box software, for energy
calculation in HVAC applications.
®
VLT DriveMotor FCP 106 & FCM 106 BACnet Operating Instructions
Technical literature and approvals are available online at
www.danfoss.com/BusinessAreas/DrivesSolutions/Documen-
tations/Technical+Documentation.
Danfoss VLT
www.danfoss.com/BusinessAreas/DrivesSolutions, PC software
download area.

1.3 Abbreviations and Conventions

ACI
ACK
ADF
ADI
AI
AO
AOC
AV
BI
BMS
BO
BV
COS
CTW
EEPROM Electrical Erasable Programmable Read Only Memory
EIA
EMC
HPFB
I/O
ISO
JCI
LCP
LED
MAV
MRV
N2
N2
master
NAK
®
DriveMotor NPA
NPT
PC
PDU
PELV
PLC
PNU
STW
Table 1.1 Abbreviations
MG03O102 - Danfoss A/S © 12/2013. All rights reserved.
®
Energy Box software is available at
Acyclical Control Interval
Acknowledge
Internal Floating Points
Internal Integers
Analog Inputs
Analog Outputs
Application Orientated Controller
Analog Values
Binary Inputs
Building Management System
Binary Outputs
Binary Values
Change Of State
Control Word
Electronic Industries Association: Specifies of the EIA
Standard RS-485-A
Electromagnetic Compatibility
High Performance Field Bus
Input/Output
International Standards Organization
Johnson Controls Inc. developers of the METASYS N2
protocol
Local Control Panel
Light Emitting Diode
Main Actual Value
Main Reference Value
METASYS N2
A N2 master is either a PC with JCI software or a
dedicated JCI controller
Not acknowledged
N2 Point Address (Each N2 Point Type has a address
range from 0 to 255)
N2 Point Type
Personal Computer
Protocol Data Unit
Protected Extra Low Voltage
Programmable Logic Control
Parameter Number
Status Word
1 1
