CDM-570A/570AL Satellite Modem with Optional Packet Processor
Ethernet-based Remote Product Management
7.4.3.3 Configuration Pages
Use the nested 'Configuration' pages to configure all operating parameters for the CDM-
570A/570AL, including the optional Packet Processor, and ODUs (Outdoor Units) when
connected.
Click, as applicable, the Modem, LAN, ARP, Routing, Managed Switch, WAN, Overhead,
Utilities, BUC, or LNB tab to continue.
7.4.3.3.1

Configuration | Modem

Chapter 6. FRONT PANEL OPERATION
Use the 'Configuration | Modem' page to configure these modem operating parameters:
• Unit Interface and Framing Mode*
•
Tx / Rx Operating Parameters
* Unit Interface Type and Framing Mode have higher priority and should be
configured before setting other parameters.
Figure 7-12. Configuration | Modem Page
7–26
• Tx Power Level
•
Carrier-in-Carrier (CnC) Parameters
MN-CDM570A
Revision 3
