CDM-570A/570AL Satellite Modem with Optional Packet Processor
Front Panel Operation

6.3.2.10 CONFIG: CnC

1) CnC operation requires that you purchase one of several available FAST
options to provide capability to a maximum of 10.239 Mbps.
2) This feature is UNAVAILABLE when operating in CDM-570 Compatible Mode.
See Sect.6.2 for further information.
• Appendix G. DoubleTalk Carrier-in-Carrier OPTION
• For more information about purchasing FAST options:
o Sect. 6.2.8 SELECT: FAST menus
o Sect. 1.3.10 Fully Accessible System Topology (FAST)
o Chapter 5. FAST ACTIVATION PROCEDURE
CnC: Mode Freq-Offset
Search-Delay
◄ ►
Use the arrow keys to select a parameter. Press ENTER.
6.3.2.10.1

(CONFIG: CnC) Mode

CDM/R-570ALunit:
CnC Mode: Off On APC
Action
For either unit: the available CnC mode selections are:
• Off
• On (normal)
For the CDM/R-570ALonly: Use the
APC controls, select APC.)
For the CDM-570A only: Use the ▲▼arrow keys to select CnC Mode as Off or On. (Continued
use of the ▲▼arrow keys entails selection of CnC-APC controls.) Press ENTER.
See Sect. G.6 Carrier-in-Carrier Automatic Power Control (CnC-APC) in Appendix G.
DoubleTalk Carrier-in-Carrier OPTION for complete details about, and setup of, the
CnC-APC feature.
(◄ ►,ENTER)
(◄ ►,ENTER)
• APC,Side-A,C-Band
• APC,Side-A,X-Band
• APC,Side-A,Ku-Band
• APC,Side-A,Ka-Band
◄ ►
arrow keys to select CnC Mode as Off or On. (For CnC-
6–39
CDM-570A unit:
Mode: Off
• APC,Side-B,C-Band
• APC,Side-B,X-Band
• APC,Side-B,Ku-Band
• APC,Side-B,Ka-Band
