CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Equipment ID
in CDM-570
Compatible Mode
(CMO=0)
(continued)
Software N/A variable
Information
Arguments for
Command or
Response to
Query
3 = up to 10239 kbps
e = Higher-order modulation:
0 = None
1 = 8-PSK/8-QAM
2 = 16QAM
3 = 8-PSK/8-QAM and 16QAM
f = Packet Processor:
0 = None
1 = IP Mod_v1
2 = IP Mod_v2
g = BUC option:
0 = None
1 = 100 Watt
2 = 150 Watt
h = G.703 Clock Extension:
0 = None
1 = Installed
i = G.703 Line Interface
0 = None
1 = Installed
Example: <0/EID?
>0/EID=1571013111x means Turbo, CDM/R-570AL, no RS codec, up to
2048bps, 8-PSK/8-QAM and 16-QAM, Packet Processor installed, 100 Watt
BUC supply installed, G.703 Clock Extension option installed
Query only.
Returns the unit's complete software information.
Example: <0/FRW?
>0/FRW=Boot:
FW-0020684-,1.1.1 ,07/12/13
Bulk1:
FW-0020683-,1.1.1,03/17/14
FW-0020685-,1.1.1,03/17/14
FW-0020686-,1.2.8,02/14/14
FW-0020687-,1.1.22,11/08/13
FW-0020688-,1.1.5 ,11/05/13
FW-0000516-,1.1.1 ,19/01/11
Bulk2:
FW-0020683-,1.1.1 ,02/14/14
FW-0020685-,1.1.1 ,02/14/14
FW-0020686-,1.2.7 ,01/28/14
Description of Arguments
8–42
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
N/A FRW? FRW=x....x
(see Description of
Arguments)
Response to
Query
