CDM-570A/570A Satellite Modem with Optional Packet Processor

4. When in Router Mode, you must use Route Tables to allow local and remote M&C access

(Figure Q-9). To restrict M&C access as Local ONLY, you must either delete the existing

route, or not configure a route, destined to remote unit's M&C subnet.

a) From the Serial CLI Main Menu, press 'R' to open the Route Table menu.

b) On Route Table menu, press a number (e.g., '3') to edit an assigned Route, or press 'D'

to delete an assigned route.

Figure Q-9. CDM-570A/570AL Route Tables
