CDM-570A/570AL Satellite Modem with Optional Packet Processor
Optional Packet Processor - Serial/Telnet CLI Operation
Selection
Tx Code Rate
Tx Modulation
Tx Spectrum Inversion
Tx Data Inversion
Tx Scrambling
Tx Output Power
Hot Key Description
R
Select the Tx code rate:
1 – 5/16
2 – 21/44
3 – 1/2
4 – 2/3
5 – 3/4
6 – 7/8
7 – 0.95
8 – 1/1
9 – VersaFEC CCM BPSK 0.488
10 – VersaFEC CCM QPSK 0.533
11 – VersaFEC CCM QPSK 0.631
12 – VersaFEC CCM QPSK 0.706
13 – VersaFEC CCM QPSK 0.803
14 – VersaFEC CCM 8-QAM 0.576
15 – VersaFEC CCM 8-QAM 0.642
16 – VersaFEC CCM 8-QAM 0.711
17 – VersaFEC CCM 8-QAM 0.780
18 – VersaFEC CCM 16-QAM 0.644
19 – VersaFEC CCM 16-QAM 0.731
20 – VersaFEC CCM 16-QAM 0.780
21 – VersaFEC CCM 16-QAM 0.829
22 – VersaFEC CCM 16-QAM 0.853
23 – VersaFEC ULL BPSK 0.493
24 – VersaFEC ULL QPSK 0.493
25 – VersaFEC ULL QPSK 0.654
26 – VersaFEC ULL QPSK 0.734
M
Select the Tx modulation type:
1 – BPSK
2 – QPSK
3 – OQPSK
4 – 8-PSK
5 – 16-QAM
6 – 8-QAM
U
Select the Tx spectral inversion type:
1 – Normal
2 – Inverted
I
Select the Tx data inversion type:
1 – Normal
2 – Inverted
B
Select the Tx scrambling type:
1 – Off
2 – On-Default
3 – On-IESS-315
P
Set a valid output power from 0.0 to 40.0 dBm (minus sign assumed).
9–42
