The CDM-570A/570AL's available EIA-530 standard pinout is popular in many applications. However, for some existing EIA-422/449 and

V.35 users, conversion is necessary. For these situations:

Figure A-1 shows the line detail for a EIA-530 to EIA-422/449 DCE conversion cable (Comtech EF Data part number CA/WR12753-x)

Figure A-2 shows the line detail for a EIA-530 to V.35 DCE conversion cable (Comtech EF Data part number CA/WR12685-x)

Appendix A. CABLE DRAWINGS
